Product Features
5-inch colorful touch screen, easy to operate.
Can be powered by AC power supply or a built-in rechargeable lithium battery.
Support 6,9 and 12-lead automatic ECG acquisition, display and heart rate detection.
：Support 3 working modes: auto, manual, and R-R.
Provide 4 sampling modes: pre-sampling, real-time sampling, periodic sampling and trigger sampling.
Support automatic pacing detection and marking.
Support suppression of baseline drift and EMG (electromyograph) interference.
Support freezing the ECG waveform on the current screen.
Output files in multiple formats, such as DAT, XML, JPEG, PDF, HL7.
Auto-saving function: save the ECG data when the report is printed.
Store, preview, export, upload, print and search patient data.
Support transmission of ECG data via wired or Wi-Fi network.
Technical Specifications：
| Safety Standard | IEC Class I, type CF |
| Acquisition Mode | 12 lead acquisition simultaneously |
| Input Circuit | Floating, protection against defibrillator and pacemaker |
| A/D Converter | 12 bit |
| Time Constant | ≥3.2s |
| Frequency Response | 0.05Hz ~ 165Hz |
| Sensitivity | 2.5, 5, 10, 20, 40 (mm/mV), Auto |
| Input Impedance | ≥50MO |
| Input Circuit Current | ≤50nA |
| Calibration Voltage | 1mV±2% |
| Noise Level | <15μVp-p |
| Anti Baseline Drift | Automatic |
| Filter | EMG Filter: 35Hz ~ 45Hz (-3dB) |
| ADS Filter: Auto (0.15-0.50Hz) | |
| HUM Filter: 50Hz/60Hz (-20dB) | |
| CMRR | >100dB |
| Patient Current Leakag | <10μA |
| Paper Speed | 5/6.25/10/12.5/25/50mm/s |
| Recording Paper | 63mm/80mm(width), 20m/30m(length), roll |
| Power Supply | AC: 110/220V, 50/60Hz |
| DC: 12V, built-in rechargeable lithium battery | |
| Dimension | 345mm×300mm×80mm; 415mm×195mm×380mm(Carton) |
| Net Weight | 2.5kgs |
| Gross Weight | 4.5kgs |
Ordering Information：
| MODEL | AUTO MEAS | AUTO ANA | LCD SIZE | DISPLAY | PAPER WIDTH | Storage | USB | Built-in SD card |
| 1103L | Yes | Yes | 5.7'' | 12CH | 80mm | Yes | Yes | 5000 |
| 1103B | Yes | Yes | 192×64 | 3CH | 63mm | NO | Optional | No |
| 1103G | Yes | Yes | 3.8'' | 12CH | 63mm | Yes | Optional | Optional |
